• Front/rear light charcoal bumpers w/rear step
• Light charcoal grille/surround
• Sealed-beam halogen headlights
• Black sail-mounted tubular neck mirrors
• Solar tinted glass
• Interval windshield wipers
• Hinged side & rear cargo doors

• Dual vinyl front bucket seats
• Passenger side underseat stowage drawer
• Inboard front armrest
• Front black vinyl floor mat
• Black vinyl steering wheel
• Headlights-on audible alert
• Front air conditioning
• Electronic AM/FM stereo radio-inc: (2) speakers, digital clock
• 12-volt pwr point in instrument panel
• Medium graphite-color cowl trim panels
• Dark graphite-color instrument panel
• Graphite-color plastic door trim panels
• Front hardboard headliner
• Dual medium graphite-color vinyl sun visors
• A-pillar interior grab handle
• Lights-inc: front dome, rear cargo
• Courtesy light switches at all doors
• Black plastic stepwell pads

• 4-wheel anti-lock braking system
• Driver & front passenger Second Generation airbags
• Medium graphite-color safety belts
• Dual-note electric horn

7.3L (444) DI TURBO DIESEL V8 "POWER STROKE" ENGINE

• dual 750-CCA batteries
• engine oil cooler
• sound reduction pkg
• vacuum pump
• fuel filter/heater/water separator
• diesel engine light cluster
• engine block heater

• 3.55 Axle Ratio
• Payload Package 1
• ETR AM/FM Stereo w/Cassette/Clock
• Fixed Rear Cargo Door Glass
• Speed Control w/Tilt Steering Wheel
• Remote Keyless Entry w/Panic Alarm
• Deluxe Engine Console Cover
• Class I Trailer Towing Package
• 130 Amp HD Alternator
• Passenger Airbag
• 4-Wheel Antilock Braking System
• Handling Package
• Headlights-On Audible Alert
• Illuminated Entry
• Light & Convenience Group
• 4-Wheel Disc Brakes
• Front beverage holders
• Variably intermittent wipers
• Power steering
• Front wheel independent suspension
• Front anti-roll bar
• Dual front impact airbags
• AM/FM radio
• ABS brakes
• Voltmeter
• Air Conditioning

• Vehicle
• Rear Door Type: Dual
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 650
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 23.0
• Total Cooling System Capacity (qts): 29.0
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4200
• Gross Axle Wt Rating - Front (lbs): 3800
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 2931
• Curb Weight - Rear (lbs): 2403
• Gross Vehicle Weight Rating Cap (lbs): 9500
• Gross Combined Wt Rating (lbs): 16,000
• Gross Combined Wt Rating (lbs): 12,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5,000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: Multi-Leaf 2-Stage
• Spring Capacity - Front (lbs): 4200
• Spring Capacity - Front (lbs): 3800
• Spring Capacity - Rear (lbs): 6195
• Axle Type - Front: Twin I-Beam
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4600
• Axle Capacity - Rear (lbs): 6340
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): 35.1
• Shock Absorber Diameter - Rear (mm): 35.4
• Stabilizer Bar Diameter - Front (in): 1.00
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.03 x 0.48
• Rear Brake Rotor Diam x Thickness (in): 12.9 x 0.54
• Tires
• Front Tire Order Code: T38
• Rear Tire Order Code: T38
• Spare Tire Order Code: 51A
• Front Tire Size: LT245/75R16E
• Rear Tire Size: LT245/75R16E
• Spare Tire Size: LT245/75R16E
• Front Tire Capacity (lbs): 3042
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 3042
• Revolutions/Mile @ 45 mph - Front: 677
• Revolutions/Mile @ 45 mph - Rear: 677
• Revolutions/Mile @ 45 mph - Spare: 677
• Wheels
• Front Wheel Size (in): 16 x 7
• Rear Wheel Size (in): 16 x 7
• Spare Wheel Size (in): 16 x 7
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 17.0
• Turning Diameter - Curb to Curb (ft): 48.0
• Turning Diameter - Wall to Wall (ft): 50.2
• Frame
• Frame Type: Single Channel
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35.0
• Fuel Tank Location: Midship
• Doors
• Side Door Type: RH Dual Hinged
• Exterior Dimensions
• Wheelbase (in): 138.0
• Length, Overall w/rear bumper (in): 211.8
• Width, Max w/o mirrors (in): 79.3
• Height, Overall (in): 84.1
• Overhang, Front (in): 30.1
• Overhang, Rear w/bumper (in): 43.8
• Ground to Top of Load Floor (in): 26.3
• Ground Clearance, Front (in): 8.1
• Ground Clearance, Rear (in): 8.1
• Rear Door Opening Height (in): 48.3
• Rear Door Opening Width (in): 54.4
• Side Door Opening Height (in): 48.3
• Side Door Opening Width (in): 47.1
• Step Up Height - Front (in): - TBD -
• Step Up Height - Side (in): 18.0
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 120.5
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 72.4
• Cargo Box Width @ Wheelhousings (in): 52.8
• Cargo Box (Area) Height (in): 52.5
• Cargo Volume (ft³): 256.5
• Interior Dimensions
• Passenger Capacity: 2
• Front Head Room (in): 42.5
• Front Leg Room (in): 40.0
• Front Shoulder Room (in): 68.4
• Front Hip Room (in): 65.6
• Summary
• Vehicle Name: Ford Econoline Cargo Van
• Body Style: E-350
• Body Code: 138
